Description of Waterproof Electrical Junction Box
- Waterproof Electrical Junction Box
- Size: 70x70x35mm
- Access Points: 8 (19mm Diameter)
- Colour: Grey
- Waterproof Rating: IP54
- CE Approval: Yes
- Junction Box Material: Hard Plastic (Not Brittle)
- Lid Design: Clip On
- CC 85291095 0.12kg N
IP54 - Standard
- The rating achieved by a junction box is defined by numbers following 'IP'
- First number defines 'Solid Particle Protection'
- Second number defines 'Liquid Ingress Protection'
- IP54 means the junction box is protected against
- Limited protection against dust ingress (no harmful deposit)
- Protected against splash water from any direction
Uses of Waterproof Electrical Junction Box
- To provide a waterproof enclosure for cable joins
- Typical applications would be with CCTV cameras to protect cable joins, connectors etc..
Advantages of Waterproof Electrical Junction Box
- Compact, dust and waterproof unit
- Low cost yet good quality with a flexible (non-brittle) lid
- The most popular size we sell
- Can be used indoors or outdoors
- Lid clips on so can be removed and replaced quickly
Disadvantages of Waterproof Electrical Junction Box
- Not large enough to house a power unit
- There are other boxes with higher IP ratings in terms of dust and liquid protection
- Lid only clips on - it is not secured in placed by screws
