DESCRIPTION of Outdoor Wireless Bridge
- 300Mbps Outdoor Wireless Bridge Kit
- Pre-configured Kit
- Note: View Installation Diagram Under Downloads Tab
- Transparent Network Bridge
- What's Included by Default
- 2x TP-Link Outdoor Access Points Incl. PoE Adapters / Injectors
- Direct Replacement For Ubiquiti Networks NanoStation Loco M2 Units
- 2x 10m CAT5e Cables
- 2x 1.5m CAT5e Cables
- Option to Purchase
- 2x 20m CAT5e Cables Instead of 2x 10m Cables
- 2x Mounting Brackets and 4x Coach Screws & Plugs
- Standards: 2.4GHz: FIEEE802.11n, IEEE802.11g: CIEEE 802.11b
- Interface & Speeds: 10/100M WAN/LAN/PoE Port x1
- Antenna: Internal 9dBi Directional Antenna
- Button: 1x RESET
- Dimensions (WxDxH): 224 x 79 x 60mm
- Power Input: AC 100-240V ~ 50/60Hz
- Wireless Features
- Band: 2.4GHz
- Wireless Speed: 300Mbps
- Wireless Security
- Wireless MAC Address Filter (Wireless Access Control)
- WEP, WPA-PSK/WPA2-PSK, WPA/WPA2 mixed
- Wireless Security: Enable/Disable
- Factory Default Settings
- IP Address: 192.168.0.254
- Default Username / Password: admin / admin
- Certificates: CEC, FCCC, RoHS
USES of Outdoor Wireless Bridge
- Used to created a wireless bridge between an existing network and additional building of up to 1km away
- Allows network to be built without running cables
ADVANTAGES of Outdoor Wireless Bridge
- Is pre-configured - ready to plug in will work with one another immediately
- It is effectively a wireless cable run from the two points and brings the network over to the new remote building
- Eliminates the need to run a physical cable
- Eliminates the need for another router or 4G service
- Is waterproof and lightning proof
- Extends the range of you wireless network over a long range
- Is capable of speeds of up to 300Mbps
- Is convenient where ability to run outdoor network cables is difficult
- Saves time and money by not having to run cables and also buy a network switch on the far end of the run
- Kit contains all you need
DISADVANTAGES of Outdoor Wireless Bridge
- While the range of the outdoor wireless bridge is extremely good, up to 1Km, environmental factors may reduce speeds and range
- Range is not as good as if a 5GHz Ubiquiti M5 version was used, which can work up to 2Km
Note: Kit now contains different models of access point. Video is illustrative
